V-3090 Compressor Head

Configuration: V-type piston design with 3 cylinders (helps deliver smoother and larger air output). Power Handling: Designed for around 7.5–10 HP motor use (motor sold separately). Compression Stage: Often dual-stage (two piston compression phases) in larger versions for higher pressure; some versions may be single-stage depending on design. Air Flow: Example spec ~ 17.5 CFM @ 90 PSI (~409 L/min). Max Pressure: Up to ~185 PSI (≈ 12.5 bar). Construction: Heavy-duty cast iron body for durability and better heat dissipation. Lubrication: Usually oil-lubricated to reduce wear and improve lifespan (not oil-free unless specified). Belt-Driven: The head is typically belt-driven from an external motor pulley.
