Multifunctional Time Delay Relay With Ac Power Supply With Base Socket

ST3P timer relays are used in all fields (industry, house, plant etc.) need controlls related to the time. Usage and Working Principle Please make the connection according to the diagram. Please adjust the delaying time by the knob. Energizethe device. Device will count the stand by time. Power led gets on when the counting occurs. During this step contact output is (NC) 4 and (NC) 5. After the time is uprelay led gets on and contact out put gets into(NO) 3 and (NO) 6. Untill it is de-energized device remains the same. ST3PA-A: 0.5sec. / 5sec. / 30sec. / 3min. ST3PA-B: 1sec. / 10sec. / 60sec. / 6min. ST3PA-C: 5sec. / 50sec. / 5min. / 30min. ST3PA-D: 10sec. / 100sec. / 10min. / 60min. ST3PA-E: 60sec. / 10min. / 60min. / 6hours. ST3PA-F: 2min. / 20min. / 2hours / 12hours. ST3PA-G: 4min. / 40min. / 4hours. / 24hours.
